Linear Guides and Rollers Built to Last

Nadella Linear Guide Systems Nadella specializes in the design and production of linear guide rail and rollers, divided into heavy and light load families, suitable for all applications where high speed and low noise are required and the operating environment is very aggressive. Rails can be supplied with a single length of 6 meters, can be cut and drilled according to customer needs and can be jointed together. The main application fields of Nadella's linear guide systems include:

  • Robotic, handler and pick & place systems
  • Packaging
  • Machine Tools
  • Wood Working Machines
  • Assembly Machines
  • Measure Instruments
  • Electro-medical Machines
  • Print machines

Nadella Linear Guide System Products

Nadella Rolbloc Carriage System
Nadella Rolbloc Carriage System

Nadella Rolbloc carriages are composed of a prismatical steel body with one or two pairs of rollers and a cylindrical outer ring. Rolbloc is designed to be used with Nadella's GU system of trapezoidal profiled rails providing high duty-cycle performance with axial guidance. Rolbloc carriages are particularly suitable for moving very heavy loads with high acceleration, for foundry and other heavy industrial applications. Rolbloc has a full line of carriages, rails, and adjustment plates to fit your specific application.

Download Nadella Rolbloc Information Sheet


Nadella Heavy Line GU System
Nadella Heavy Line GU System Guide Rails and Accessories

Nadella heavy line GU system trapezoidal guide rails are cold drawn solid bearing steel with induction hardened race surfaces that can be supplied both with sandblasted or ground surface treatment. The system provides radial loading and axial guidance for medium to heavy loads of up to 41,000 pounds of force per roller. The Nadella heavy line GU system has a variety of accessories including guide rollers, roller wheels, floating guide rollers, lubricators, and mounting pins.

Download Nadella Heavy Line GU System Information Sheet


Nadella Heavy Line GP System
Nadella Heavy Line GP System Guide Rails and Accessories

Nadella heavy line GP system guide rails are cold drawn solid bearing steel with induction hardened race surfaces that can be supplied both with sandblasted or ground surface treatment. The system provides radial loading and axial freedom for medium to heavy loads of up to 41,000 pounds of force per roller. The Nadella heavy line GP system has a variety of accessories including guide rollers, roller wheels, cam followers, and lubricators.

Download Nadella Heavy Line GP System Information Sheet


Nadella Base-Line FWS and FWH System
Nadella Base-Line FWS and FWH System Guide Rails and Accessories

The Nadella base-line system is Nadella's "economy" offering and was designed with space saving in mind. The guide rails are made with extruded aluminum and hardened steel shafts. These rails are designed for light to medium loads and are capable of thriving in aggressive environments like wood dust and shavings. The Nadella base-line rail system is available in different geometrical configurations for different applications. The shafts for the FWS and FWH systems are also available in stainless steel.

Download Nadella Base-Line FWS and FWH System Information Sheet


Nadella Base-Line DC and C System
Nadella Base-Line DC and C System Guide Rails and Accessories

The Nadella base-line system is Nadella's "economy" offering and was designed with space saving in mind. The guide rails are made with extruded aluminum and hardened steel shafts. These rails are designed for light to medium loads and are capable of thriving in aggressive environments like wood dust and shavings. The Nadella base-line rail system is available in different geometrical configurations for different applications. The shafts for the DC and C systems are also available in stainless steel or chromium plated.

Download Nadella Base-Line DC and C System Information Sheet


Nadella C-Line LS System
Nadella C-Line LS System Guide Rails and Accessories

The Nadella C-line LS system uses one rail shape, "C", and with a combination of specific rollers and fixed or floating bearings, constructions can be created that balance errors in parallelism, height and angle. The Nadella C-line guide rails are made of cold drawn solid bearing steel, induction hardened and are available in two surfaces: zinc-plated or nickel-plated. Guide rails, guide rollers, and standard carriages are the components of this line from Nadella.

Download Nadella C-Line LS System Information Sheet


Nadella Flexi-Line 645 FWN System
Nadella Flexi-Line 645 FWN System Guide Rails and Accessories

Nadella's flexi-line guide system is designed to adapt to individual requirements. Available in standard dimensions (ISO 645 compatible) the guide system can also be customized: bore holes and threads can be made to any distance and the carriages can have over lengths and unique hole patterns. Made of aluminum, these rails are 45% lighter than rails made of steel and they offer superior performance and cost savings. The rails are also available in stainless steel. Guide rails and carriages are the components of this line from Nadella.

Download Nadella Flexi-Line 645 System Information Sheet


Nadella U-Line LML System
Nadella U-Line LML System Guide Rails and Accessories

Nadella's U-line LML system is the perfect solution when extremely compact dimensions are required or when cost is a big factor. Designed to handle manual and low precision movements and simple linear motion, the rails are made of extruded aluminum with a hard anodized surface which offers significant protection against wear and corrosion. The rollers are made of corrosion-resistant bearing steel with polyamide coated outer rings. This combination results in low-noise linear motion with no stick-slip. Carriages in compact U-profile Guide rails, guide rollers and carriages are the components of this line from Nadella.

Download Nadella U-Line LML System Information Sheet


Nadella V-Line FS System
Nadella V-Line FS System Guide Rails and Accessories

Nadella V-line FS system guide rails are cold drawn solid bearing steel with induction hardened race surfaces that can be supplied both with sandblasted or ground surface treatment. The system provides radial loading and axial freedom for medium to heavy loads of up to 41,000 pounds of force per roller. The Nadella V-line FS system has a variety of accessories including guide rollers, roller wheels, cam followers, and lubricators.

Download Nadella V-Line FS System Information Sheet


Nadella Multi-Motion-Line Circular System
Nadella Multi-Motion-Line Circular System Guide Rails and Accessories

Nadella's Multi-Motion-Line Circular System rails are cold drawn solid bearing steel with induction hardened race surfaces and can be custom configured. Based on the FS family or profiles, the rails can be used as single sectors, joined together with alignment blocks to create an entire circumference, or joined with straight pieces to obtain oval or ring circuits. For protection against corrosion Nadella recommends nickel plating for both the straight and circular pieces. Guide rails, guide rollers, and standard carriages are the components of this line from Nadella.

Download Nadella Multi-Motion-Line Circular System Information Sheet
